Used 2023 Chevrolet Silverado MD Work Truck

VIN: 1HTKHPVK0PH554657
Stock #: 44412A

3,473 mi.

Vehicle Details

Trans.:Highway Service Transmission, Automatic close-ratio 6 SPD with double overdrive, Allison, A1700HS ratios: 3.10 1st, 1.80 2nd, 1.40 3rd, 1.00 4th, 0.70 5th, 0.61 6th Highway Series, 19.5K GVW & 26K GCW Max., requires PTX and park pawl. Available with GVWs
Drivetrain:Rear Wheel Drive
Engine: 8 Cylinder Engine
Fuel Type:Diesel
Ext. Color:White
Price
$53,800
people recently viewed this vehicle*

Description

Standard Features

  • Air conditioning, single-zone
  • Assist handle, front passenger and driver on A-pillars
  • Cruise control, steering wheel-mounted
  • Driver Information Center, 3.5-inch diagonal monochromatic display, provides warning messages and basic vehicle information
  • Floor covering, Graphite-colored rubberized-vinyl
  • Instrumentation, 6-gauge cluster featuring speedometer, fuel level, engine temperature, tachometer, voltage and oil pressure
  • Interior trim, Jet Black/Dark Ash (Required and only available with (H2Q/H2R) Dark Ash seats with Jet Black interior accents.)
  • Mirror, inside rearview manual day/night
  • Seat Belt, Black
  • Speedometer, miles/kilometers
  • Steering column, manual Tilt-Wheel
  • Steering wheel, urethane
  • Upfitter switch kit provides up to 4-30 amp circuits to facilitate installation of aftermarket electrical accessories located on the instrument panel
  • Visors, driver and front passenger, vinyl
  • Windows, manual driver and front passenger
  • Alternator, 150 amps
  • Axle lubricant, rear, synthetic oil EmGard Fe -75W-90
  • Axle to End of Frame, 49″ (Requires wheelbase (ED5) 201″, (ED9) 165″, (ER2) 189″ or (FQT) 141″. Not available with (G40), (GP1) or (GP8) rear air suspension.)
  • Axle, Open rear axle, non-locking rear
  • Batteries, heavy-duty dual 1100 cold-cranking amps includes battery Box mounted to left side under Cab
  • Brakes, hydraulic, heavy duty Bosch/Meritor/Wabco system with 4-channel (ABS) (Includes (J69) driveline park brake.)
  • Capped Fuel Fill
  • Emissions, USA 50 State certified
  • Engine, Duramax 6.6L Turbo-Diesel V8, B20-Diesel compatible 350 hp @ 2700 rpm, 700 lb.-ft. torque @ 1600 rpm
  • Exhaust brake
  • Exhaust system, right side exit, behind rear wheels (Requires (FQT) 141″ wheelbase.)
  • Front axle, 6,250 lb. (2,835 kg), Dana Spicer D800-N, “I”-beam, non-driving (Requires (FTW) 6,250 lb. front suspension. Includes (G68) rear shock absorbers. Not available with rear air suspensions.)
  • Front suspension, 6,250 lb. (2,835 kg) multi-leaf, includes shock absorbers (Not available with rear air suspensions.)
  • Fuel tank, rear only, 40 gallon mounted between frame side rails and behind rear axle
  • Fuel, diesel B20
  • GVWR, 16,500 lb. (7484 kg) (Silverado 4500 HD 2WD Regular Cab models require One of the following combinations: (1) (FTC) 6.25k front axle and (FTW) 6.25k front suspension and (GL4) 11k rear axle and (GR3) 11k rear suspension. (2) (FTC) 6.25k front axle and (FTW) 6.25k front suspension and One of the following rear axles: (HD2) 13.5k rear axle, (HD1) 15k rear axle or (J27) 15.5k rear axle and (GR4) 13.5k rear suspension. (3) (FTA) 7k front axle and (FK6) 7k front suspension and (FN1) 10k rear axle or (GL4) 11k rear axle and (GR3) 11k rear suspension or (G40) 12K Rear air suspension. (4) (FTA) 7k front axle and (FK6) 7k front suspension and (HD1) 15k rear axle or (J27) 15.5k rear axle and One of the following rear suspensions: (GR4) 13.5k rear suspension, (FU7) 15.5k rear suspension, (GP1) 13.5K rear air suspension, (GP8) 15.5k rear air suspension, (91B) 13.5k LiquidSpring prep single volume rear suspension, (91C) 13.5k LiquidSpring prep stacked volume rear suspension, (91D) 15.5k LiquidSpring prep single volume rear suspension or (91E) 15.5k LiquidSpring prep stacked volume rear suspension.)
  • Incomplete vehicle
  • Neutral-at-Stop Automatic transmission shifts to neutral when the service brake is depressed while the vehicle is at a complete stop, and remains in neutral until the service brake is released
  • Rear axle, 11,000 lb. (4,999 kg) Dana Spicer S14-110, single reduction
  • Rear axle, 4.10 ratio Max road speed: 79 MPH
  • Rear suspension, 11,000 lb. (4,990 kg) multi-leaf, vari-rate (Not available with air suspension.)
  • Rear wheel drive
  • Shock Absorbers, rear (Included with (FTC) 6,250 lb. front axle.)
  • Steering, power (Bosch S2 8014 Plus)
  • Trailer brake controller, integrated
  • Trailering provisions, trailering wire harness only, trailer combined (Stop/Tail/Turn) connection socket and harness mounted at rear of frame.
  • Transmission shift control calibration, fuel sense Performance
  • Wheelbase, 141″ (358.1 cm), 60″ CA (Requires (F0C) 49″ axle to end of frame, (F0D) 63″ axle to end of frame or (F0K) 91″ axle to end of frame and (NPR) exhaust. Requires (PCJ) Vocational Specific Heavy Suspension Package, when ordering (FTA) 7,000 lb. Front axle/(FK6) 7,000 lb. Front suspension or (FTL) 8,000 lb. Front axle/(FSN) 8,000 lb. Front suspension and/or (FU7) 15,500 lb. rear suspension. Not available with rear air suspensions or (91B), (91C), (91D) or (91E) prep for LiquidSpring rear suspension.)
  • Antenna, fixed mast
  • Bumper, front, Black
  • Door handles, Black
  • Front fender extension, painted body color
  • Glass, solar absorbing, tinted
  • Grille guard screen, insect protection (mounted behind grille)
  • Grille, base, molded in color, Black
  • Headlamps, halogen projector-beam
  • Lamps, Smoked Amber roof marker
  • Lamps, cargo area, Cab mounted with switch on center switch bank
  • Lamps, rear, stop/turn/backup (1-piece assembly) with license plate light
  • Mirrors, outside high-visibility vertical camper-style, Black with manual folding and extension and lower convex spotter glass
  • Spare tire delete
  • Wheel, spare delete
  • Audio system feature, 4-speaker system
  • SiriusXM, delete
  • Brake, parking, driveline park brake system
  • Daytime Running Lamps, with automatic exterior lamp control
  • Horn, single-note
  • OnStar, delete
  • Rear Vision Camera, display integrated into Radio (Shipped loose in Cab for upfitter installation.)

Vehicle Location

Jim Charlon Ford
269 South China Lake Blvd
Ridgecrest, CA 93555

VEHICLE DATA
Certain specifications, prices and equipment data have been provided under license from Chrome Data Solutions (\’Chrome Data\’). Ā© 2026 Chrome Data Solutions, LP. All Rights Reserved. This information is supplied for personal use only and may not be used for any commercial purpose whatsoever without the express written consent of Chrome Data. Chrome Data makes no guarantee or warranty, either expressed or implied, including without limitation any warranty of merchantability or fitness for particular purpose, with respect to the data presented here. All specifications, prices and equipment are subject to change without notice.

ESTIMATE MPG
EPA mileage ratings are supplied by Chrome Data Solutions, LP for comparison purposes only. Your actual mileage will vary, depending on how you drive and maintain your vehicle, driving conditions, battery pack age/condition (hybrid models only) and other factors.

Based on 2019 EPA mileage ratings. Your MPGe/MPG and driving range will vary depending on driving conditions, how you drive and maintain your vehicle, battery-pack age/condition, and other factors.

PRICING
Vehicle pricing is believed to be accurate. Tax, title and registration are not included in prices shown unless otherwise stated. Manufacturer incentives may vary by region and are subject to change. Vehicle information & features are based upon standard equipment and may vary by vehicle. Monthly payments may be higher or lower based upon incentives, qualifying programs, credit qualifications, residency & fees. No claims, or warranties are made to guarantee the accuracy of vehicle pricing, payments or actual equipment. Call to confirm accuracy of any information.

*Number of views in last 30 days

Technical Specifications

  • Vehicle Name: Chevrolet Silverado MD
  • Body Style: Regular Cab Chassis Cab
  • Body Code:
  • Drivetrain: Rear Wheel Drive
  • Passenger Capacity: 1, 3
  • Number of Passenger Doors: 2
  • Gross Axle Wt Rating – Front: 6250, 7000, 8000
  • Gross Axle Wt Rating – Rear: 10000, 11000, 13500, 15000, 15500
  • Curb Weight – Front: 4635, 4676, 4691, 4704, 4723, 4735, 4750, 4756, 4761, 4770, 4771, 4781, 4791, 4791, 4814
  • Curb Weight – Rear: 2803, 2845, 2849, 2856, 2863, 2890, 2898, 2905, 2905, 2909, 2916, 2930, 2948, 2950, 2957, 2965, 2972, 2973, 2986, 2987, 2990, 2997, 3000, 3008, 3011, 3011, 3015, 3029, 3032, 3033, 3033, 3040, 3047, 3054, 3054, 3060, 3067, 3068, 3071, 3078, 3081, 3085, 3092, 3092, 3093, 3099, 3100, 3113, 3114, 3145, 3152, 3164, 3166, 3224, 3231, 3245
  • Gross Vehicle Weight Rating Cap: 14001, 15000, 16000, 16500, 17500, 18000, 19500, 21500, 22940, 23500
  • Gross Combined Wt Rating: 26000, 30000, 34000, 35000, 37000
  • Engine Order Code: L5D
  • Engine Type: Turbocharged Diesel V8
  • Displacement: 6.6L/402
  • Fuel System: Direct Injection
  • SAE Net Horsepower @ RPM: 350 @ 2700
  • SAE Net Torque @ RPM: 700 @ 1600
  • Trans Order Code: MA6, MB6, MBV, MBW, MBX, MBY, ME0, MF0, MG0, MH1, MHV, MI0, MIA, MIU, MIX, MJ0, MWA, MWB
  • Trans Type: 6
  • Trans Description Cont.: Automatic
  • Trans Description Cont. Again:
  • First Gear Ratio (:1): 3.10
  • Second Gear Ratio (:1): 1.80
  • Third Gear Ratio (:1): 1.40
  • Fourth Gear Ratio (:1): 1.00
  • Fifth Gear Ratio (:1): 0.70
  • Sixth Gear Ratio (:1): 0.61
  • Reverse Ratio (:1): – TBD –
  • Clutch Size: N/A
  • Trans Power Take Off: , Yes
  • Trans PTO Access: , RH/LH
  • Transfer Case Model:
  • Transfer Case Gear Ratio (:1), High:
  • Transfer Case Gear Ratio (:1), Low:
  • Transfer Case Power Take Off:
  • Cold Cranking Amps @ 0° F (Primary): 1100, 1300, 2250
  • Cold Cranking Amps @ 0° F (2nd): 1100, 1300, 2250
  • Cold Cranking Amps @ 0° F (3rd): , 2250
  • Maximum Alternator Capacity (amps): 150, 150 & 220, 220
  • Maximum Alternator Watts: – TBD –
  • Total Cooling System Capacity: 48
  • Engine Oil Cooler: Yes
  • Frame Type: High Strength Low Alloy Steel
  • Sect Modulus Rails Only: 8.08 Front/10.93 Belly/8.47 Rear
  • Frame RBM: 404000 Front/546500 Belly/423500 Rear
  • Frame Strength: 50000
  • Frame Thickness: 0.3125
  • Suspension Type – Front: Multi-Leaf
  • Suspension Type – Rear: , Air, Multi-Leaf
  • Spring Capacity – Front: 6250, 7000, 8000
  • Spring Capacity – Rear: 11000, 12000, 13500, 15500
  • Axle Type – Front: Dana Spicer I-Beam
  • Axle Type – Rear: Dana Spicer Single Reduction
  • Axle Capacity – Front: 6250, 7000, 8000
  • Axle Capacity – Rear: 10000, 11000, 13500, 15000, 15500
  • Axle Ratio (:1) – Front:
  • Axle Ratio (:1) – Rear: 4.10, 4.30, 4.56, 4.88
  • Shock Absorber Diameter – Front: 50.8
  • Shock Absorber Diameter – Rear: , 48.5
  • Stabilizer Bar Diameter – Front: , 1.26
  • Stabilizer Bar Diameter – Rear:
  • Front Tire Order Code: XDK, XDL, XEK, XEL, XEY, XEZ, XHD, XMF
  • Rear Tire Order Code: YAL, YAM, YAS, YAT, YEY, YEZ, YHD, YMF
  • Spare Tire Order Code: , ZBF, ZBG, ZBK, ZBR, ZEY, ZEZ, ZHD, ZMF
  • Front Tire Size: 225/70R19.5G, 225/70R19.5H
  • Rear Tire Size: 225/70R19.5G, 225/70R19.5H
  • Spare Tire Size: , 225/70R19.5G, 225/70R19.5H
  • Front Tire Capacity: 7940, 8000
  • Rear Tire Capacity: 15000, 15500
  • Spare Tire Capacity: , 15000, 15500, 7940, 8000
  • Revolutions/Mile @ 45 mph – Front: – TBD -, 640, 643, 645, 649
  • Revolutions/Mile @ 45 mph – Rear: – TBD -, 640, 643, 645, 649
  • Revolutions/Mile @ 45 mph – Spare: , – TBD -, 640, 643, 645, 649
  • Front Wheel Size: 19.5 x 6.75
  • Rear Wheel Size: 19.5 x 6.75
  • Spare Wheel Size: , 19.5 x 6.75
  • Front Wheel Offset: – TBD –
  • Rear Wheel Offset: – TBD –
  • Spare Wheel Offset: , – TBD –
  • # of Bolt Holes – Front: 8
  • # of Bolt Holes – Rear: 8
  • # of Bolt Holes – Spare: , 8
  • Front Wheel Material: Aluminum, Steel
  • Rear Wheel Material: Aluminum & Steel, Aluminum, Steel
  • Spare Wheel Material: , Aluminum, Steel
  • Steering Type: Pwr
  • Steering Ratio (:1), On Center: 16.6
  • Steering Ratio (:1), At Lock: 19.6
  • Turning Diameter – Curb to Curb: 41.2, 47.2, 53.2, 56.2, 60.7, 63.7, 66.7
  • Turning Diameter – Wall to Wall: 42.8, 48.8, 54.8, 57.8, 62.3, 65.3, 68.3
  • Brake Type: Pwr
  • Brake ABS System: 4-Wheel
  • Brake ABS System (Second Line):
  • Disc – Front (Yes or ): Yes
  • Disc – Rear (Yes or ): Yes
  • Front Brake Rotor Diam x Thickness: 15.375 x 1.54
  • Rear Brake Rotor Diam x Thickness: 15.375 x 1.54
  • Drum – Front (Yes or ):
  • Front Drum Diam x Width:
  • Drum – Rear (Yes or ):
  • Rear Drum Diam x Width:
  • Fuel Tank Capacity, Approx: 25, 40, 65
  • Aux Fuel Tank Capacity, Approx:
  • Fuel Tank Location: Behind Rear Axle, Front & Rear, Front
  • Aux Fuel Tank Location:
  • Front Head Room: 42.8
  • Front Leg Room: 45.28
  • Front Shoulder Room: 66.02
  • Front Hip Room: 60.75
  • Wheelbase: 141, 165, 189, 201, 219, 231, 243
  • Length, Overall: 224.4, 238.4, 262.3, 266.5, 286.3, 290.4, 298.2, 298.6, 310.3, 328.4, 356.0, 360.0
  • Width, Max w/o mirrors: 92.7
  • Height, Overall: 82.47, 82.49, 82.55, 82.62, 82.64, 82.66, 82.68, 82.69, 82.79, 82.7, 82.81, 82.95
  • Overhang, Front: 34.4
  • Overhang, Rear w/o bumper: 49, 63, 75, 83, 91
  • Front Bumper to Back of Cab: 115.47
  • Cab to Axle: 107.87, 120.08, 138.19, 150, 161.81, 59.84, 83.86
  • Cab to End of Frame: 109.1, 123, 133.1, 146.9, 151.1, 157.1, 169.3, 170.9, 174.9, 182.7, 183.1, 194.9, 213, 240.6, 244.5
  • Ground to Top of Load Floor:
  • Ground to Top of Frame: – TBD –
  • Frame Width, Rear: 34.1
  • Ground Clearance, Front: – TBD –
  • Ground Clearance, Rear: – TBD –
  • Front Frame Rating: – TBD –
  • Seventh Gear Ratio (:1):
  • Eighth Gear Ratio (:1):
  • Ninth Gear Ratio (:1):
  • Tenth Gear Ratio (:1):
  • Eleventh Gear Ratio (:1):
  • Twelfth Gear Ratio (:1):
  • Thirteenth Gear Ratio (:1):
  • Fourteenth Gear Ratio (:1):
  • Fifteenth Gear Ratio (:1):
  • Sixteenth Gear Ratio (:1):
  • Seventeenth Gear Ratio (:1):
  • Eighteenth Gear Ratio (:1):
  • Nineteenth Gear Ratio (:1):
  • Twentieth Gear Ratio (:1):
  • Second Reverse Gear Ratio (:1):
  • Third Reverse Gear Ratio (:1):
  • Fourth Reverse Gear Ratio (:1):
  • Fifth Reverse Gear Ratio (:1):
  • Sixth Reverse Gear Ratio (:1):
  • Body Weight (uncalculated):
  • Driver Weight: 350
  • Axle Ratio – Low Rear (:1):
  • Driver Ratio: 1
  • Torque @ Clutch Engage: – TBD –
  • Cab to Body: 3
  • Grade (%): 2
  • Frontal Area:
  • Governed Engine Speed (RPM): 2900
  • Torque Converter: 1.764
  • Front Wheel Description Cont.:
  • Rear Wheel Description Cont.:
  • Spare Wheel Description Cont.:
  • Static Loaded Radius: – TBD -, 14.9, 15.1, 15.2, 15
  • Front Bolt Pattern: 8 Hole JIS 10.83″
  • Rear Bolt Pattern: 8 Hole JIS 10.83″
  • Spare Bolt Pattern: , 8 Hole JIS 10.83″
  • Number Of Tires Front: 2
  • Number Of Tires Rear: 4
  • Number Of Tires Spare: 0, 1
  • Transmission Manufacturer: Allison
  • Transmission Type: A1700EVS Allison, A1700HS Allison, A1700MH Allison, A1700PTS Allison, A1700RDS Allison, A1750EVS Allison, A1750HS Allison, A1750MH Allison, A1750RDS Allison, A2700EVS Allison, A2700HS Allison, A2700MH Allison, A2700PTS Allison, A2700RDS Allison, A2750EVS Allison, A2750HS Allison, A2750MH Allison, A2750RDS Allison
  • Engine Series: Duramax
  • Body Length Default Value: , 11, 12, 13, 14, 14, 15, 16, 17, 19, 20, 9
  • Engine Horsepower At RPM:
  • Engine Horsepower At Max Speed RPM:
  • Max Speed For Gradeability: 65, 70, 75, 79
  • Country of Origin: United States Truck – Incomplete Vehicle
  • Model Group: Silverado MD
  • Vehicle Segment: Chassis
  • Vehicle Type: Standard Cab
  • Engine Displacement Units: 6.6, 6.6
  • Engine Camshaft: OHV, OHV
  • Engine Block Type: iron, iron
  • Engine Cylinder Count: 8, 8
  • Engine Valve Count: 4, 4

Special Ford Courtesy Vehicle

Ford Courtesy Vehicles are low mileage used vehicles that are eligible for New Vehicle Retail Incentive Offers and the balance of the New Vehicle Limited Warranty. These vehicles were formerly used by our customers and cared for by our very own service department.

×

Almost there!

Complete this short form and we will get in touch with you soon. Thank you!

  • This field is for validation purposes and should be left unchanged.

This site is protected by reCAPTCHA and the Google Privacy Policy and Terms of Service apply.

Find Your Next Vehicle

search by model, color, options, or anything else...
